AM-45 PU Precision Medical Tube Extrusion Line
- Model: AM-45
- Brand: Aituo
- Delivery: 15-20 DAYS
- Warranty: 2 YEAR
×Enter your message
Product Description
AM-45 PU Precision Medical Tube Extrusion Line
PRODUCT SPECIFICATIONS:
Voltage: 380V/3P/50Hz
Material: PU granular material
Product: PU medical tube, pipe diameter 4-8mm
Output: 25-30 m/min
Equipment center height: 1000mm
Operation direction: from right to left
Machine size: 11*1.2*2.4m
Total installed power: 30KW
Actual power consumption: 18 degrees/hour
Laser on-line diameter measurement technology: non-contact main line real-time accurate detection of the outer diameter of the catheter, with an accuracy of 0.003MM
Details
Medical catheter extrusion production line PVC Pipe Production Line Machinery consists of the following seven parts:
|
No.
|
Item
|
Qty
|
Note
|
|
1
|
Φ45 PU single screw extrusion host
|
1SET
|
Multiple types are options
|
|
2
|
Precision extrusion die for medical tube
|
1SET
|
4-8MM
|
|
3
|
4m stainless steel vacuum cooling water tank
|
1SET
|
|
|
4
|
LST-25 single-axis diameter gauge
|
1SET
|
|
|
5
|
Small belt servo traction cutting machine
|
1SET
|
|
|
6
|
Belt conveyor receiving table
|
1SET
|
|
|
7
|
Weilun touch screen PLC control system
|
1SET
|
|
|
8
|
5HP air-cooled chiller
|
1SET
|
